MOBILE SOLAR SOLUTION
Elka
Choose energy independence by combining this mobile solar solution with your zero-emission generators.
3600W
Power
14 400 Wh
Capacity
3 kits
Available
INSTALLATION
5 minutes
1 person + 4 solar panels.
As simple as possible.
capacity
8 800 Wh/day
Depending on the square meters installed, add several kits in parallel to increase production.
SOLAR SURFACE
10 m²
Peak power 1760 W. Good efficiency from morning to night thanks to the adjustable tilt.
AUTONOMY and ROBUSTNESS
ALL TERRAIN
To reduce your environmental impact, Ekla offers you its best features: its lightness, ultra-mobility, robustness, and power. In the forest, on a construction site, or off-grid, Ekla is as discreet as it is indispensable.
WHAT’S INCLUDED IN THE EKLA KIT
PRODUCE YOUR OWN GREEN ENERGY ANYWHERE
PRODUCE YOUR OWN GREEN ENERGY ANYWHERE
- 4 foldable solar panels in a suitcase
- Flight case for transport
- Cables suitable for our electric generators
SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ELECTRIC
Rated power
1500 W (x4 panels)
Peak power
1760 Wc (4×440 Wc)
Production capacity/day
8800 Wh*
Output voltage
380 Vdc
Output current
0 to 12 A
Yield
18%
Powerbank connection (MPPT)
Anderson (50A max)
Reel Recharge Time
6h (100%)
Wattman charging time
12h or 6h with 2 kits Ekla
Compatible with solar charging
1 x 230 VAC – 16A Single Phase Socket Monocrystalline Guard Lines A
Others
Several possible arrangements
Rain and dust resistant
Tiltable thanks to the folding stand for optimal solar performance
Panel lifespan exceeding 10 years
PHYSIcs
Dimensions (during transport)
130 x 70 x 75 cm, stackable, on swivel casters with brakes – 100 kg (including box)
Weight
14 kg/panel x 4 (56 kg total)
Solar surface
10 m2 (2.42 x 4 panels of 2.18 x 1m)
Deployed surface
20 m2 (10 x 2m or 5 x 4m)
SIZE YOUR IMPACT
Estimate your carbon footprint with Elka
